Features:
The belt body does not delaminate, with high strength, small stretch, impact resistance, friction resistance and tear resistance.
Purpose:
Suitable for conveying materials under dry conditions with an inclination angle below 20 degrees.
Technical requirements:
Products can be organized according to MT/T914-2019 and other standards.
Safety Features:
Conveyor belts are self-extinguishing for flame combustion, have excellent flame retardant properties, and have good antistatic properties.
|
Product category
|
Tensile strength (minimum)
|
Recommended thickness of cover glue
|
|
Radial（N/mm）
|
Weft (N/mm)
|
|
680S/Level 4
|
680
|
265
|
1.5+1.5
|
|
800S/Level 5
|
800
|
280
|
1.5+1.5
|
|
1000S/Level 6
|
1000
|
300
|
1.5+1.5 ≥1.5~≤3.0mm
|
|
1250S/Level 7
|
1250
|
350
|
1.5+1.5 ≥1.5~≤3.0mm
|
|
1400S/Level 8
|
1400
|
350
|
1.5+1.5≥1.5~ ≤ 3.0mm
|
|
1600S/Level 9
|
1600
|
400
|
1.5+1.5≥ 1.5~ ≤ 3.0mm
|
|
1800S/Level 10
|
1800
|
400
|
1.5+1.5≥1.5~ ≤3.0mm
|
|
2000S/Level 11
|
2000
|
400
|
1.5+1.5 ≥ 1.5~ ≤ 3.0mm
|
|
2240S/Level 12
|
2240
|
450
|
1.5+1.5≥1.5~ ≤ 3.0mm
|
|
2500S/Level 13
|
2500
|
450
|
According to customers need
|
Minimum roller diameter selection (for reference only)
|
Standard selection
|
Recommended Minimum Window Roller Diameter
|
|
680S/Level 4
|
500
|
|
800S/Level 5
|
630
|
|
1000S/Level 6
|
630
|
|
1250S/Level 7
|
800
|
|
1400S/Level 8
|
800
|
|
1600S/Level 9
|
1000
|
|
1800S/Level 10
|
1000
|
|
2000S/Level 11
|
1250
|
|
2240S/Level 12
|
1250
|
|
2500S/Level 13
|
1400
|
